Koch Filter 102-091-009 MULTI-PLEAT XL11-SC 1" Semi-Standard Capacity MERV 11 Pleated Panel Filter Size 18x18x1
Rated 3.5/5 based on 11 customer reviews

Koch Filter 102-091-009 MULTI-PLEAT XL11-SC 1" Semi-Standard Capacity MERV 11 Pleated Panel Filter Size 18x18x1

$117.15 $201.98

Koch Filter 102-091-009 MULTI-PLEAT XL11-SC 1" Semi-Standard Capacity MERV 11 Pleated Panel Filter Size 18x18x1

Part Number : 102-091-009
Size : 18x18x1
Depth : 1 in
Packaging : 12 ea/case

Multi-Pleat XL11

The Koch Multi-Pleat XL11 is a medium efficiency extended surface pleated panel filter, engineered to provide higher initial efficiencies and better overall performance than standard pleated filters.

The Multi-Pleat XL11 carries a MERV 11 fractional efficiency rating in accordance with ASHRAE Test Standard 52.2. The filter will also provide an Initial Dust Spot Efficiency of 45%, and an Average Dust Spot Efficiency of 55-60% in accordance with ASRAE Rest Standard 52.1.

The MERV 11 efficiency ratings provided by the Multi-Pleat XL11 make the filter an excellent upgrade from disposable filters and ordinary pleated filters in applications such as hospitals, laboratories and pharmaceutical.

Multi-Pleat XL11 Construction

The Multi-Pleat XL11 is produced with a highly specialized, dual-layered 100% synthetic media, developed by Koch Filter specifically for use in extended surface air filters. The new media is composed of an upstream electrostatically enhanced layer (the E-layer), and a downstream mechanical layer (the M-layer). The dual-layered construction of Multi-Pleat Series XL11 overcomes a common problem found in single-layered electrostatically charged filters. In filters produced with single-layered media, the effectiveness of the electrostatically charged media decreases over time as the filter becomes dirty and the charge dissipates. As the effectiveness of the electrostatically enhanced E-layers decreases, the downstream mechanical M-layer takes over.

Two Media Area Capacity Levels

Standard Capacity XL11-SC filters provide a combination of efficiency, economy, and excellent overall performance. Standard Capacity XL8 filters are an excellent choice in applications where filter change schedules are based on preventive maintenance schedules.
