Koch Filter 102-499-007 MULTI-PLEAT XL11-SC 1" Standard Capacity MERV 11 Pleated Panel Filter Size 16x25x1
- Category: COVID-19 PPE, Koch Filter
Koch Filter 102-499-007 MULTI-PLEAT XL11-SC 1" Standard Capacity MERV 11 Pleated Panel Filter Size 16x25x1
Part Number : 102-499-007
Size : 16x25x1
Depth : 1 in
Packaging : 12 ea/case
Multi-Pleat XL11
The Koch Multi-Pleat XL11 is a medium efficiency extended surface pleated panel filter, engineered to provide higher initial efficiencies and better overall performance than standard pleated filters.
The Multi-Pleat XL11 carries a MERV 11 fractional efficiency rating in accordance with ASHRAE Test Standard 52.2. The filter will also provide an Initial Dust Spot Efficiency of 45%, and an Average Dust Spot Efficiency of 55-60% in accordance with ASRAE Rest Standard 52.1.
The MERV 11 efficiency ratings provided by the Multi-Pleat XL11 make the filter an excellent upgrade from disposable filters and ordinary pleated filters in applications such as hospitals, laboratories and pharmaceutical.
Multi-Pleat XL11 Construction
The Multi-Pleat XL11 is produced with a highly specialized, dual-layered 100% synthetic media, developed by Koch Filter specifically for use in extended surface air filters. The new media is composed of an upstream electrostatically enhanced layer (the E-layer), and a downstream mechanical layer (the M-layer). The dual-layered construction of Multi-Pleat Series XL11 overcomes a common problem found in single-layered electrostatically charged filters. In filters produced with single-layered media, the effectiveness of the electrostatically charged media decreases over time as the filter becomes dirty and the charge dissipates. As the effectiveness of the electrostatically enhanced E-layers decreases, the downstream mechanical M-layer takes over.
Two Media Area Capacity Levels
Standard Capacity XL11-SC filters provide a combination of efficiency, economy, and excellent overall performance. Standard Capacity XL8 filters are an excellent choice in applications where filter change schedules are based on preventive maintenance schedules.
Koch Filter 102-499-007 MULTI-PLEAT XL11-SC 1" Standard Capacity MERV 11 Pleated Panel Filter Size 16x25x1
Part Number : 102-499-007
Size : 16x25x1
Depth : 1 in
Packaging : 12 ea/case
Multi-Pleat XL11
The Koch Multi-Pleat XL11 is a medium efficiency extended surface pleated panel filter, engineered to provide higher initial efficiencies and better overall performance than standard pleated filters.
The Multi-Pleat XL11 carries a MERV 11 fractional efficiency rating in accordance with ASHRAE Test Standard 52.2. The filter will also provide an Initial Dust Spot Efficiency of 45%, and an Average Dust Spot Efficiency of 55-60% in accordance with ASRAE Rest Standard 52.1.
The MERV 11 efficiency ratings provided by the Multi-Pleat XL11 make the filter an excellent upgrade from disposable filters and ordinary pleated filters in applications such as hospitals, laboratories and pharmaceutical.
Multi-Pleat XL11 Construction
The Multi-Pleat XL11 is produced with a highly specialized, dual-layered 100% synthetic media, developed by Koch Filter specifically for use in extended surface air filters. The new media is composed of an upstream electrostatically enhanced layer (the E-layer), and a downstream mechanical layer (the M-layer). The dual-layered construction of Multi-Pleat Series XL11 overcomes a common problem found in single-layered electrostatically charged filters. In filters produced with single-layered media, the effectiveness of the electrostatically charged media decreases over time as the filter becomes dirty and the charge dissipates. As the effectiveness of the electrostatically enhanced E-layers decreases, the downstream mechanical M-layer takes over.
Two Media Area Capacity Levels
Standard Capacity XL11-SC filters provide a combination of efficiency, economy, and excellent overall performance. Standard Capacity XL8 filters are an excellent choice in applications where filter change schedules are based on preventive maintenance schedules.
